Shimano SG-8C56 CYBER NEXUS 8-Speed Internal Hub w/Coaster Brake

SG-8C56 CYBER NEXUS 8-Speed Internal Hub w/Coaster Brake SG Getriebenabe /Nabenschaltung

Shimano SG Getriebenabe /Nabenschaltung SG-8C56 CYBER NEXUS 8-Speed Internal Hub w/Coaster Brake

Vous trouverez ici le dessin des pièces détachées pour Shimano SG Getriebenabe /Nabenschaltung SG-8C56 CYBER NEXUS 8-Speed Internal Hub w/Coaster Brake. Sélectionnez la pièce détachée pour vélo désirée dans la liste des pièces détachées pour votre Shimano vélo et commandez simplement en ligne. Nous avons toujours beaucoup de pièces détachées Shimano en stock pour vous.

Pos.	Numéro d'article	Description
1	Y-37H98010	Internal Assembly (Axle Length 184.9 mm) Y37H98010
2	Y-37G98020	Brake Shoe Unit (3 pcs.) Y37G98020
3	Y-37E08000	O-Ring Y37E08000
4	Y-33Y19000	Stop Ring ( 9.6 mm) Y33Y19000
5	Y-37H98020	Ring Gear Unit Y37H98020
6	Y-37H98030	Carrier Unit Y37H98030
7	Y-35P11000	Ring Gear 1 Y35P11000
8	Y-34R80000	Ring Gear 1 Stop Ring Y34R80000
9	Y-34R98030	Ball Retainer O (3/16" x 26) Y34R98030
10	Y-37H98040	Hub Axle Unit (Axle Length 184.9 mm) Y37H98040
11	Y-35P98060	Clutch Unit Y35P98060
12	Y-34R21000	Return Spring A Y34R21000
13	Y-37H98050	Driver Unit Y37H98050
14	Y-34R98110	Right Hand Dust Cap A w/Seal Y34R98110
15	Y-34R0E000	Right Hand Dust Cap B Y34R0E000
16	Y-34R98070	Ball Retainer P (3/16" x 13) Y34R98070
17	Y-35R98060	Right Hand Cone w/Seal Y35R98060
18	Y-35M05000	Driver Plate Y35M05000
19	Y-35R98070	Lock Washer Y35R98070
20	Y-35M03000	Right Hand Lock Nut A (4.7 mm) Y35M03000
21	Y-31414010	Cap Nut (3/8") Y31414010
22	Y-33M39510	Non-turn Washer 5L (Brown) Y33M39510
22	Y-33M39610	Non-turn Washer 6L (White) Y33M39610
22	Y-33M39710	Non-turn Washer 7L (Gray) Y33M39710
23	Y-35P28000	Left Hand Lock Nut (3 mm) Y35P28000
24	Y-35P22000	Stop Nut Y35P22000
25	Y-37G98070	Brake Arm Unit (3 Serration) Y37G98070
26	Y-33098110	Ball Retainer B (3/16" x 16) Y33098110
27	Y-35J11100	Hub Shell Slide Spring Y35J11100
28	Y-32203220	Sprocket Wheel 16T (Silver) Y32203220
28	Y-32203420	Sprocket Wheel 18T (Silver) Y32203420
28	Y-32203520	Sprocket Wheel 19T (Silver) Y32203520
28	Y-32203620	Sprocket Wheel 20T (Silver) Y32203620
28	Y-33060000	Sprocket Wheel 21T (Silver) Y33060000
28	Y-33060100	Sprocket Wheel 22T (Silver) Y33060100
28	Y-33060200	Sprocket Wheel 23T (Silver) Y33060200
29	Y-32120100	Snap Ring C Y32120100
30	Y-33Z20500	Non-turn Washer 5R (Yellow) Y33Z20500
30	Y-33M39600	Non-turn Washer 6R (Silver) Y33M39600
30	Y-33M39700	Non-turn Washer 7R (Black) Y33M39700
31	Y-33F98090	Brake Arm Clip Unit (5/8") Y33F98090
31	Y-33F98100	Brake Arm Clip Unit (3/4") Y33F98100
32	Y-75M06000	Clip Screw (M6 x 16) Y75M06000
33	Y-31727200	Clip Nut Y31727200
34	Y-70800500	TL-8S50 Carrier Unit Tool Y70800500
35	Y-70800300	TL-8S30 Carrier Unit Tool Y70800300
36	Y-70800400	TL-8S40 Right Hand Cone Installation Tool Y70800400
37	Y-70800600	TL-8S11 Right Hand Cone Removal Tool Y70800600
38	Y-04120800	Internal Hub Grease (Net. 100g) Y04120800
39	Y-00298010	WB maintenance oil set Y00298010
40	Y-00201000	WB maintenance oil (1L) Y00201000
41	Y-00201100	Bottle Y00201100
42	Y-37H98060	Internal Assembly (Axle Length 184.9 mm) & Brake Arm Unit Y37H98060
43	Y-37G98100	Brake Shoe Unit & Brake Arm Unit Y37G98100
-	Y-34R0D000	Right Hand Hub Cup Y34R0D000
